| Feature | Specification / Description |
|---|---|
| Machine Type | CNC Cylindrical Grinding Machine |
| Make / Brand | Jones & Shipman (J&S) |
| Country of Origin | United Kingdom (UK) |
| Centre Distance | 600 mm |
| Centre Height | 200 mm |
| Max. Grinding Diameter | Up to Ø 300 mm (approx.) |
| Swing Over Bed | Approx. Ø 400 mm |
| Control System | CNC (Typically Fanuc or Siemens, model dependent) |
| Wheel Head Configuration | Angular / Straight – Depending on model variant |
| Grinding Wheel Size | Ø 400 mm × Width 40–80 mm (approx.) |
| Table Traverse (Z-Axis) | 600 mm |
| Cross Travel (X-Axis) | 200 mm |
| Workhead | Live / Dead Centre or Chuck Mountable |
| Tailstock | Manual or Hydraulic (depending on configuration) |
| Coolant System | With Filtration System |
| Dressing Attachment | Inbuilt CNC dresser or manual (depends on version) |
| Motor Power | Approx. 5–7.5 HP |
| Machine Dimensions | Approx. 2500 × 2000 × 1800 mm |
| Machine Weight | Approx. 3500 – 4000 kg |
| Applications | Precision OD/ID grinding of shafts, tools, sleeves, rollers, and cylindrical parts |
| Condition | (Specify: Used / Refurbished / Excellent) |
| Included Accessories | CNC Panel, Coolant Tank, Wheel Dresser, Tailstock, Steady Rest (if applicable) |
