| Feature | Specification / Description |
|---|---|
| Machine Type | Cylindrical Grinding Machine |
| Make / Brand | TOS |
| Country of Origin | Czechoslovakia (Czech Republic) |
| Grinding Length | 2000 mm |
| Center Height | 320 mm |
| Max. Swing Over Bed | Approx. Ø 640 mm |
| Max. Workpiece Diameter | Up to Ø 600 mm (approx.) |
| Workpiece Weight | Up to 1500 – 2000 kg (depending on center support and model) |
| Wheel Head Movement | Manual or Hydraulic (depending on model) |
| Workhead Speed | Variable – typically 20 to 250 RPM |
| Tailstock | Yes – with quill and taper |
| Wheel Size | Ø 500 mm × Width 80 mm (approx.) |
| Coolant System | Equipped with filtration and pump |
| Motor Power | Approx. 7.5 to 10 HP |
| Control | Manual / Semi-Automatic |
| Applications | Precision grinding of shafts, rollers, spindles, and cylindrical components |
| Condition | (Specify: Used / Refurbished / Good Working Condition) |
| Machine Dimensions | Approx. 4500 × 2200 × 1900 mm |
| Machine Weight | Approx. 6000 – 7000 kg |
| Included Accessories | Steady rests, tailstock, coolant tank, wheel dresser |
