Shaving Cutter Diameter Range: 64 mm to 320 mm
-
Module Range: 1 to 12
-
Number of Teeth: 13 to 240
-
Pitch Block Diameter: 73 mm to 320 mm
-
Max Cutter Width: 40 mm
-
Grinding Wheel Swivel (Pressure Angle): 5° to 21°
-
Grinding Slide Swivel (Helix Angle): ±35°
-
Vertical Slide Travel: 240 mm
-
Feed Speeds: 0.25, 0.5, and 1 m/min
-
Teeth Feed Rates: 5, 20, 30, or 40 teeth/min
-
Grinding Spindle Speed: ~690 rpm
-
Grinding Slide Diameter: 762 mm
-
Spindle Motor Power: 1.1 kW
-
Total Machine Power: Approx. 3.9 kW
