| Specification | Details |
|---|---|
| Manufacturer / Model | CUGIR (Romania) – Likely FD-Series or similar |
| Machine Type | Supine-type gear milling machine |
| Max Workpiece Diameter | 1,000 mm |
| Max Module Capacity | Up to 12 mm |
| Max Workpiece Width | Approx. 400–500 mm (varies by setup) |
| Table Diameter | ~800–1,000 mm (estimated) |
| Table Bore Diameter | 160 mm |
| Head Swivel Angle | ±45° (for helical gear cutting) |
| Spindle Speed Range | 40–300 rpm |
| Feed Rates | Adjustable; multi-axis manual feed |
| Motor Power | 7.5–10 kW |
| Installed Power | ~12–15 kW |
| Machine Weight | ~8,000–10,000 kg (approximate) |
| Application | Suitable for large gear milling, including spur, helical, and spline gears |
| Condition | Typically available refurbished or good used condition |
